Intelligent RS485 Electric Power Meter Single Phase 2 Wire Energy Meter DIN Rail Mounting LCD Backlight Display AC 230V 5-80A

Intelligent RS485 Electric Power Meter Single Phase 2 Wire Energy Meter DIN Rail Mounting LCD Backlight Display AC 230V 5-80A

Features:

1.Practical: This energy meter is with RS485 communication. 5 + 1 digits LCD display shows the total power consumption.

2.Advanced technology: It features high reliability, small volume, light weight, beautiful appearance, advanced technology.

3.Good performance: It has good anti-electromagnetic interference, low power consumption, high precision, high overload, high stability, anti-electricity stolen and long life.

4.Indoor installation: This table is suitable for the measurement of rated frequency 50Hz or 60Hz single phase ac active electricity, used for fixed indoor installation.

5.High quality: The meter is fully in accordance with the relevant technical requirements of GB / T17215.321-2008 national standard and the IEC62053 international standard of grade 1 or level 2 single-phase energy meter, which directly and accurately measure active energy consumption.

Description:

This product is a very practical single-phase 2P guide rail digital meter with RS485 Modbus communication protocol.

Specifications:

Brand: comwintop

Model: TTE-XTPM-1P-S

Type: Single Phase Two Wire Electronic Type

Material: Metal + ABS

Reference Voltage: 230V AC

Reference Current: 5 (80) A.

Nominal Frequency: 50Hz / 60Hz

Constant Pulse: 1000imp / kWh

Display: LCD 5 + 1

Power consumption: ≤ 2W, 10VA

Operating Temperature: -10 ~ 50 °C

Notes:
1. Please allow 0-1 inch error due to manual measurement. Thanks for your understanding.
2. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from real object.
